High flow water filter element HF40PP005A01

High flow water filter element HF40PP005A01 is widely used in the pretreatment of ultra-large flow reverse osmosis in electric power, electronics, chemical industry, metallurgy and other industries, or as a security filter, and pretreatment protection of ultrafiltration systems. It has the characteristics of large flow, small footprint, good economic benefits, and convenient operation.

Specification parameters

Filter specification model: HF40 series HF60 series

Filtration (microns): 5, 10, 15, 25, 40, 70

Filter diameter (in/mm): 6.5/165

Element Length (in/mm): 40/1016 60/1524

Features of the filter element:

It allows high-flow media to pass through the filter material, which has the advantages of high efficiency, low pressure loss and long life.

The outside-in and inside-out structure of the high-flow filter element makes it easy to replace the filter element while keeping pollutants intercepted on the outside of the filter element.

There is a pp support frame inside the filter element, which can withstand a pressure difference of 0.245MPa at most.

The β value of the filter element is over 1000.

Multiple filter elements can be installed in the filter housing, which can be used in a wide range of flow rates, whether it is started or in continuous operation.

The filter element is durable, and the filter can be configured with the least and most economical configuration.
