Hydac 0660D010BN4HC Replacement Filter

NX filter designs and manufactures hydraulic filters, filter elements and other products, which can replace 60,000 models of more than 200 brands in the world. They are widely used in construction machinery, mining machinery, electric power industry, steel, machine tools, petrochemical, shipbuilding

Product	Hydraulic filter	Model	0660D010BN4HC
Type	High pressure filter	Size	(OD)90.2(ID)48.2(H)328 mm
Filter material	Glass fiber	Filtration accuracy	3 microns
End cover	Galvanized sheet	Inner frame	Galvanized punching sheet
Sealing ring	Nitrile rubber	Delivery time	7 days for standard parts

Application

Used to filter solid particles in hydraulic and lubricating systems.

Standard test

The design and manufacture of NX filter elements comply with relevant standards:

Compatibility test of ISO2943 and hydraulic medium

ISO/DIS 3724 circulation fatigue strength

Resolution of ISO/DIS 4572 multiple passes

ISO/DIS 2942 Quality Assurance (Bubble Test)

ISO 3723 end cap load test

ISO2941 rupture test

Features

-The use of depth-type filter material, gradual pore structure, gradient filtration, can effectively intercept particles and improve service life.

-The use of high-tech support materials can not only support the filter material from being deformed under pressure, but also protect the material from damage during processing.

-The special spiral belt is used to connect the filter layer firmly, and at the same time, the fixed folding distance ensures the uniform flow rate of the fluid penetrating the filter layer; it not only improves the pressure drop, but also prolongs the service life of the filter element.
