PP Pleated Filter Element
PP Pleated Filter Element Size: custom size Application range: It can be widely used in the pharmaceutical industry, food industry, chemical industry, organic solvent filtration, electronics, oil field water filters, etc.
Features:
PP filter media and graded pore structure provide highly consistent performance
Contains no adhesives to minimize contamination
High flow, low pressure drop
High surface area, high flow rate and long service life reduce maintenance costs
The filter is manufactured, washed, tested and packaged in a Class 1000 clean room environment
Manufactured according to the certified ISO9001 quality system.
Details:
Specification | Filter media | Polypropylene |
Supporting Material | Polypropylene | |
End caps | Polypropylene | |
Center core | Polypropylene | |
Hardware | Polypropylene | |
Gasket/O-rings | Slicone | |
Buna-N | ||
Viton | ||
EPDM | ||
Length | 9.75"~40" | |
Dimentions | Outside Diameter | 2.67" |
Specification can be customized | ||
Performance | Retention ratings | 0.1,0.22,0.45,0.8,1,2,3,5,10,20,30um |
Max differential pressure | 75 psid(5.1bar)@68℉(20℃) 40 psid(2.8bar)@150℉(65℃) | |
Recommended change out differential pressure | 35psid(2.4bar) | |
Application scope:
Electronics industry: Industrial water pre-filtration
Catering industry: Wine, drinking water, beer, soda, brewery
Petroleum industry: Water injection
Pharmaceutical industry: Fine filtration of medicines, biological products, medicine solvents, compressed air and other liquids.
Chemical industry: Filtration of various organic solvents, acids and lyes.
Optical film: Protective film filtration, functional film, OCA glue, high-performance adhesive, etc.
